Monoaxial Charge Output

Name: Wibro-Akustyka
Address: ul. Grabowska 248, Ostrów Wielkopolski, 63-400, PL

Type	Sensitivity	Weight	Temp. Min/Max
Miniature Charge Accelerometers
A/28/E Data Sheet	0,4 pC/g	0,19 g	-50°C/+200°C
A/27/E Data Sheet	2 pC/g	1,8 g	-50°C/+220°C
A/24/E Data Sheet	5 pC/g	2 g	-50°C/+200°C
General Purpose Charge Accelerometers
A/23/E Data Sheet	8 pC/g	3,4 - 4,9 g	-50°C/+250°C
A/22 Data Sheet	26 pC/g	12 g	-50°C/+250°C
A/20 Data Sheet	30 pC/g	12,5 g (A/20, A/20/T) 27 g (A/20/TC)	-50°C/+250°C
High Sensitivity Charge Accelerometers
A/29 Data Sheet	100 pC/g	46 g (A/29, A/29/T) 51 g (A/29/TC)	-50°C/+250°C
A/21 Data Sheet	360 pC/g	95 g (A/21, A/21/T) 102 g (A/21/TC)	-50°C/+250°C
Seismic/Micro G Charge Accelerometers
A/600 Data Sheet	1,2 nC/g	115 g	-50°C/+250°C
A/800 Data Sheet	9 nC/g	400 g (A/800, A/800/T) 407 g (A/800/TC)	-50°C/+250°C
Industrial Charge Accelerometers
A/52/F Data Sheet	100 pC/g, 12 pC/g nom.	100 g (A/52/F) 123 g (without cable)	+260°C +400°C (HT)
A/81/F Data Sheet	230 pC/g, 35 pC/g nom.	150 g 160 g (without cable)	+260°C +400°C (HT)
A/301/F Data Sheet	220 C/g, 25 pC/g nom.	150 g	+260°C +400°C (HT)
A/107/F Data Sheet	100 C/g, 10 pC/g nom.	80 g	+260°C +400°C (HT)
